    Keypower 10 KVA FAWDE Diesel Generators
    Keypower 10 KVA FAWDE Diesel Generators
    • 产品详情
    • 询单留言

    Keypower 30 KVA FAWDE Diesel Generators

    Keypower 30 KVA FAWDE Diesel Generators

    DIESEL GENERATOR SPECIFICATIONS

    1. Powered by reliable engines
    2. Branded alternator
    3. Open type, silent type  generator
    4. ISO, CE certified

    GENERATOR SPECS:
    Rated output: 2 to 2,000kW/2 to 2,500kVA
    Rated voltage: L-N 110 to 277V, L-L 220 to 480V
    Rated frequency: 50/60Hz

    ENGINE:
    Brands: Cummins, Perkins,  Deutz, Doosan, Mitsubishi, Kubota, Yanmar or other reliable Chinese engines such as Fawde and Laidong.
    Cooling method: closed water-cooled or air-cooled
    Starting method: electric start or recoil start
    Rated speed: 1,500/1,800/3,000/3,600rpm
    Noise level: 56 to 75dB, 7 meters away

    ALTERNATOR:
    Brands: Stamford, Leroy Somer, Mecc Alte and Keypower brushless alternator
    Rated output: 8 to 2,000kW/10 to 2,500kVA
    Rated voltage: L-N 110 to 277V, L-L 220 to 480V
    Rated frequency: 50/60Hz
    Phase: 3-phase, 4-wire or 1-phase, 2-wire
    Connection: y or other type connection
    Rated speed: 1,500/1,800rpm
    Excitation: harmonic excitation or phase compound or brushless
    Voltage regulation: AVR automatic
    1.0% voltage regulation in static conditions (maximum)
    Protection class: IP23
    Control panel: Deepsea, ComAp, Keypower

    THE PANEL IS PROVIDED WITH:
    Standard engine instrumentation
    Voltmeter with selector switch
    Ammeter with selector switch
    Frequency meter
    Current transformers
    MCB of suitable rating with overload and short-circuit protection
    Optional with AMF control panel or with ATS (automatic transfer switch)

    APPLICATIONS:
    With advanced reasonable structure, high efficiency, low vibration and noise, smooth running, high reliability, easy handling, KEYPOWER generators are widely used in national defense, telecommunications, construction site, commercial buildings, industrial and mining sites, oil fields, roads, ports, villas, banks, hospitals etc.

    ANY QUESTION, PLEASE CONTACT US DIRECTLY.
